盧森系列
產品名稱 : 盧森系列
產品介紹
貝力瑞士盧森系列 - 無懈可擊的設計感
盧森系列獨特的鑽石紋表面處理與同步木紋浮雕效果,在加上歐洲頂級四面倒角技術,真實的表現出真實木紋地觸感, 並且創造出全方位完美木質地板的視覺放大效果。
Product Description 產品規格:
Thickness (厚度) | 8 mm |
Size (尺寸) | 1380mm x 193mm x 8mm |
Packing (包裝) | 8 pieces each pack = 2.13M² (0.65 坪) |
Wearing Surface (耐磨層) | AC4 |
Core Materials (基材標準) | E1 standard, EN14041:2004, CE |
Click (鎖扣) | KronoSwiss Locking System |
Surface Style (表層壓紋) | Chromepore |
Performance Tests - EU Standard 歐規標準
Characteristics | Method | Unit | Requirements | Typical values | Results |
Abrasion Class﹝耐磨指數﹞ | EN 13329 | AC 4 : IP ≧ 4000 | ≧ 4000 | PASS合格 | |
Impact Resistance﹝耐衝擊性﹞ | EN 13329 | ≧ IC 2 | ≧ IC 2 | PASS合格 | |
Resistance to Staining ﹝耐沾汙性﹞ |
EN 13329 | Rating | Group 1 & 2: 5, Group 3: 4 | Group 1 & 2: 5, Group 3: 4 | PASS合格 |
Resistance to Cigarette Burns ﹝香菸灼燒抗性﹞ |
EN 13329 | Rating | ≧ Grade 4 | ≧ Grade 4 | PASS合格 |
Effect of Furniture Leg ﹝桌腳搬動-表面摩擦測試﹞ |
EN 13329 | No damage with type 0 indentor | No damage with type 0 indentor | PASS合格 | |
Effect of Castor Chair ﹝辦公椅滾輪-表面摩擦測試﹞ |
EN 13329 | No damage or visible | No damage or visible | PASS合格 | |
Externally controlled FormaldehydeTest﹝甲醛測試﹞ |
EN 120 | E1 HDF | E1 HDF | PASS合格 | |
Reaction to Light ﹝抗光性﹞ | EN 13329 | Blue wool scale: Not worse than 6 |
Blue wool scale: Not worse than 6 |
PASS合格 | |
Reaction to Light ﹝抗光性﹞ | EN ISO9239-1 | Grey Matter: Not worse than 4 |
Grey Matter: Not worse than 4 |
PASS合格 | |
Reaction to Fire ﹝抗火性﹞ | EN 12667 | Grey Matter: Not worse than 4 |
Flame-retardant, Bulding Class Cfl-s1 |
PASS合格 | |
Reaction to Fire ﹝抗火性﹞ | R¹° 23/50[(m²K)/W] | R¹° 23/50[(m²K)/W] | |||
Reaction to Fire ﹝抗火性﹞ | 7 mm: 0.054 | 7 mm: 0.054 | |||
Reaction to Fire ﹝抗火性﹞ | 8 mm: 0.059 | 8 mm: 0.059 | |||
Reaction to Fire ﹝抗火性﹞ | 10 mm: 0.075 | 10 mm: 0.075 | |||
Reaction to Fire ﹝抗火性﹞ | 12 mm: 0.089 | 12 mm: 0.089 |
Performance Tests-CNS Standard 經濟部標準檢驗局國家標準
Characteristics | Method | Unit | Requirements | Typical values | Results |
Formaldehyde Emission ﹝甲醛釋放量﹞ |
CNS1349 | mg/L | ≦ 1.5 | 0.8 | PASS合格 |
Taber Abrasion Test ﹝表面耐磨﹞ |
CNS11367 | rounds | ≧ 6000 rounds﹝轉﹞ | ≧ 18800 rounds﹝轉﹞ | PASS合格 |
Water Resistance - Type D ﹝耐水性D試驗﹞ |
CNS8058 | 無面裂、剝離、顯著變色及光澤變化等現象 | 無面裂、剝離、顯著變色及光澤變化等現象 | PASS合格 | |
Impact Resistance ﹝耐衝擊性 W2-300, 50cm﹞ |
CNS2215 | 無龜裂、破壞及剝離現象, 且無凹陷之情形 |
無龜裂、破壞及剝離現象, 且無凹陷之情形 |
PASS合格 | |
Density of HDF﹝密度﹞ | CNS2215 | g/cm³ | ≧ 900 | 920 | PASS合格 |
Fungus Resistance ﹝抗菌測試﹞ |
ASTM G-21 | Rating | 1.微量生長 ﹝黴菌生長面積 ≦10%﹞ |
0.無黴菌生長 | PASS合格 |
Fire Behavior - According to CNS 7614 (1994) - Type A:
Article | Method | Unit | Requirements | Type Values | Results |
Ignition Time﹝火源加熱時間﹞ | CNS 7614 | Sec | 60 | Level 1 ﹝一級防焰標準﹞ | |
After-Flame Time﹝餘焰時間﹞ | CNS 7614 | Sec | ≦ 1 | 0.0 | PASS合格 |
After-Glow Time﹝餘燼時間﹞ | CNS 7614 | Sec | ≦ 60 | 0.0 | PASS合格 |
Char Distance﹝碳化長度﹞ | CNS 7614 | cm | ≦ 10 | 5.8 | PASS合格 |
a matter needing attention注意事項:
1. 為使地板永久如新,建議在大門入口處使用刮泥墊或在室內使用室內拖鞋,傢俱類也建議下方使用保護墊,使地板的壽命延長。 |
2. 擦拭地板水要盡量擰乾。 |
3. 長時間紫外線照射地板,會使其顏色變暗或變亮,這是一種自然的現象。 |
